The reference plane (green) : This plane is typically used to define the top of the bar. They serve as a reference, and can define the insertion axis.The planes are displayed when you activate the Show plane box in the first tab: To create profiles that are more radically different from the already available profiles, see section Extending the bar profile library below. Set Docking Point : Center is the midpoint/center of the attachment preview (left click to apply dot) H is the height / X is the horizontal axis direction / Y is the occlusal axis direction. Snap to Gingiva : Left-clicking this tab will make the attachment adjust to the tissue surface. ( similar to a path of insertion in C & B ) "View" is setting the rotation to the current view that you have moved the model ( Bar ) to on the screen. "Top" restricts the movement to orbital rotation on top of the bar. "Free" allows total freedom of movement in all directions. Rotate : This affects the rotational movement around the pivot point of an attachment. Type : Select a file type from the drop down list.Īpply to Last Selected Part : If this option is selected, when you modify, or individually or simultaneously, it will apply automatically the changes to the last selected part placed. You can find here a list of the available libraries. Library : Select a name from the drop down list. Retention: 3D mesh to add to the construction in order to create retentions. Visualizer: 3D mesh for visualization purposes only. Attachment: 3D mesh to add to the construction. Add : Add an attachment selection from the drop-down list. In the ATTachment tab, the following features are available: This axis can be changed by a view dependent setting of the model or can be viewed by having the check box checked.ĭefine : this drop down will allow you to Set From View Rotate the model to a desired position for your Path of Insertion, then click this button. Insertion Axis: Use plane section: Insertion axis of the secondary frame that will fit over the bar. See section advanced profile editing.Īuxiliary Planes: Show planes section Planes This box, once checked, allows you to use the advanced profile editing.
This is to accommodate extra space of the papilla around the implant/tooth. This box, once checked, allows you to use borders around the implants. This allows you to preview the result of your changes made to the prosthesis. In the PROFILE tab there are many features:īars and Pillars : Adjustment of bar and pillars simultaneously.īar only : Adjustment of the bar only.īorders : Adjustment of the borders only.
If you would like to create a custom profile please see: Extending the bar profile library If you made a mistake you can re-apply the profile.
The Options section will allow you to apply a particular profile to a selection or segment of the bar or to the whole bar. This save will allow you to rename your new bar profile and it will be accessible in the Type pulldown for future use. If this shape is one that you would like to use again, you can click Save. In the Bar Profile parameters pulldown you can adjust many sections of the bar in various ways to suit your desired shape. Here you can choose the Type of bar profile from the pulldown. In the Profiles window you will see the Select profile section. Once the initial steps have been completed and you have reached the Wizard window Bar Design the Profiles window will appear. You can change profile parameters by unfolding the Bar Profile Parameters expander.
To select a specific segment, simply click on it. By selecting the Apply to selection radio button, you can apply new profile choices only to the currently selected bar segment (marked by purple with yellow outlines). Select the desired profile from the Type drop-down box.īy default, the newly selected profile will be applied to the entire bar.
